JC40 Small Twin Carburettor Filter
Part Number: JC40
This smaller length twin carburettor filter can be used where space is at a premium and the JC50 filter will not fit. As with the JC50, the two outer layers of foam provide optimum filtration and load-up capacity while the inner layer is made of a special self extinguishing filter foam. Together, they give the best combination for air flow, engine protection and safety.
Measurements
A - (Internal Height mm) Distance from face of baseplate and the inside face of the filter
B - (Width mm) External width of the filter not including the lug
C - (Length mm) External length of the filter.
D - (Overall Height mm) Overall external height of the filter
| Part No. | A (Internal height) | B (Width) | C (Length) | D (Overall height) |
|---|---|---|---|---|
| JC40/25 | 25 | 142 | 379 | 50 |
| JC40/40 | 40 | 142 | 379 | 65 |
| JC40/65 | 65 | 142 | 379 | 90 |
| JC40/100 | 100 | 142 | 379 | 125 |
| JC40/125 | 125 | 142 | 379 | 150 |
